Polaris Ranger XP HD EV RZR RZRS RZR4 Crew, Yamaha Rhino, Kawasaki Mule Teryx, Arctic Cat Prowler
|
|
|
|
|
|
|
|
The LED Parking Lights and Turn Signal Kit
|
|
|
The LED Parking Lights & Turn Signal Kit will fit all years for the Polaris Ranger XP / HD / EV / TM / 400 / 425 / 500 / 700 / 800 / RZR / RZRS / RZR4 and Crew, all years for the Yamaha Rhino, all years for the Kawasaki Teryx & Mule, and all years for the Arctic Cat Prowler. (SEE NOTES BELOW) This kit can be easily installed on any Side-by-Side (side x side), UTV, Golf Cart, Club Car, Sand Car, Dune Buggy, etc.
Note: some like amber lights front and rear, order from the drop down box (BELOW) a) Light Options: Amber Kit: All 4 Amber lights.
|
|
Note: the 2009-2010 Polaris Ranger XP / HD and the 2010 Ranger Crew use our custom turn signal switch (TSS) mounting strap. This custom strap will allow the tilt steering to have full range of motion with the turn signal switch mounted just under the steering wheel. Order from the drop down box (BELOW) b) TurnSignal Switch: 09-10 Ranger XP/HD (TSS) Strap or 2010 Ranger Crew (TSS) Strap.
Note: the 2010 Polaris Ranger EV & 400 use our custom turn signal switch (TSS) mounting plate. This custom plate was designed to mount the turn signal switch just below the steering wheel on the plastic shroud. Order from the drop down box (BELOW) b) TurnSignal Switch: 2010 Ranger EV/400 (TSS) Plate. This custom (TSS) mounting plate is only available on the LED turn signal kits.
Note: the 2008-2010 Arctic Cat Prowler with tilt steering, you may want to use a 5" inch hose clamp to mount the turn signal switch.
Note: the 2010 Kawasaki Teryx with the plastic shroud molded up to the steering wheel, you will need to cut some of the plastic to make room for mounting the turn signal switch OR use a 5" inch hose clamp around the plastic shroud.
|
|
|
|
|
|
|
|
|
ALL KITS: In Stock & Ready to Ship!
|
|
|
|
This is a 12 volt LED Parking Lights and Turn Signal Kit with 2 Amber (front) and 2 Red (rear) Dual Mode DOT approved LED lights. The 4 Dual Mode LED light kit comes with a turn signal switch, which has a pilot light for the turn signals and 4-way emergency flashers (hazard warning). The turn signal switch has a pull on flare tab for the 4-way hazard lights, an added 18" ground wire and the hardware to mount it to your steering column.
The four Dual Mode LED Lights are 4x 2 rectangular with 12 Colored (red or amber) Light Emitting Diodes each. They are chrome based, come with both clear & colored lenses and are hard wired with encapsulated electronics to eliminate corrosion. They have 3 lead wires each, one for ground, normal mode (parking lights) and high mode (turn signals), which is equal to 24 LEDs on high mode.
The special LED Electronic Flasher has the 3 pin connections for LOAD, PILOT and POWER. This special electronic LED flasher is also quite, no annoying clicking sounds.
The Parking Light Switch is a LED illuminated rocker switch and is easy to install, vibration resistance, and will illuminate when turned on.
The kit includes: 2 Amber and 2 Red Dual Mode DOT approved LED lights with both colored and clear lenses, the Turn Signal Switch with an extra 18 ground wire with ring tong connector (for better grounding of the turn signal switch) and the hardware to mount it to your steering column, the special LED Electronic Flasher, the LED illuminated rocker switch for parking lights, an in-line fuse holder, a 3 amp fuse, the self tapping screws for mounting the lights and flasher, the mounting installation instructions, the wiring instructions & diagram, and all the help and support you need from EZ Turn Signal Kits.
This kit can be easily installed, it does not go into any factory wiring, and it is a completely independent system that comes with the wiring diagram and instructions. Each wire has a different color and the wiring diagram shows where each colored wire goes. I include my phone number and e-mail address with the instructions, so if you have any questions about your installation you can contact me.
This kit was originally developed for my 2009 Polaris Ranger XP and my customers have installed their kits on the Polaris Ranger 425 / TM / 500 / 700 / 800 / XP / HD, Razor (RZR / RZR-S / RZR-4) and Crew, the Yamaha Rhino, the Kawasaki Mule and Teryx, and the Arctic Cat Prowler. This kit can be easily installed on any 12 volt Side-by-Side UTV, Golf Cart, Club Car, Sand Car, Dune Buggy, etc.
This turn signal switch has been installed on thousands of units, very nice and easy to operate. The Motor Vehicle Department and your local police departments will be impressed. Everyone who rides on the street, off road, at the dunes or in congested riding areas, should have turn signals for there added safety.
|
|
|
Total Power Draw: .84 amps, that's less than 1 amp with the four LED parking and hazard lights ON!
|
|
|
<<< hold mouse over pictures to see other examples >>>
|
|
|
|
|
|
|
2 Amber 4"x2" DM LED Lights
2 Red 4"x2" DM LED Lights
1 Turn Signal Switch
|
|
1 LED Flasher
1 Fuse Holder & Fuse
1 LED Rocker Switch
|
|
Hardware for mounting components
Mounting Installation Instructions
Wiring Instructions & Diagram
|
|
|
Options: We have some Custom Kit Brackets along with a Wire & Connector Kit that you may want to use with your Turn Signal Kit. Any of these options purchased with your kit, will save you money!
|
|
|
|
|
|
|
|
|
|
ALL KITS: In Stock & Ready to Ship!
|
|
|
|

|
|
|
|
